Dimensions
379.2*379.2*230 mm
(Propellers excluded)
450 mm axis diameter
372*372*247 mm
(Propellers excluded)
450 mm axis diameter
Flight time
30 min (no wind & no load)
30 min (no wind & no load)
Max video transmission distance
Max wind speed resitance
72 km/h | 20 m/s | 39 knot
72 km/h | 20 m/s | 39 knot
Max flight speed
10 m/s (GPS); 22 m/s (ATTI)
10 m/s (GPS); 22 m/s (ATTI)
Max height
120 m (GPS) / ATTI - no limitation
120 m (GPS) / 1.6 km (ATTI)
Max tilt angle
ATTI: 12.5°; ATTI (fast): 25°
ATTI: 12.5°; ATTI (fast): 25°
Flight mode
GPS
ATTI
Sport
Cruise
Orbit
Headless+
Manual +
GPS
ATTI
Cruise
Return safe
Dynamic Return-to-Home
One-Key Return-to-Home
Signal Lost Return-to-Home
Low Battery Auto Return-to-Home
Low Battery Auto Payload-release
One-Key Return-to-Home
Signal Lost Return-to-Home
Low Battery Auto Return-to-Home
Battery
Intelligent Battery 6600 mAh
97.68 Wh14.8V 4S LiPo
(#18650 cell inside)
Durable & Easy to maintain
Slide In / Out
Standard LiHV Battery
6500 mAh 99.8 Wh15.2V 4S LiHV
Install from the top cover
Hovering precision
±0.5 m (vertical);
±0.5 m (horizontal)
±0.5 m (vertical);
±0.5 m (horizontal)
Operating frequency
5180 - 5875 MHz
2405 - 2475 MHz (drone)
5645 - 5965 MHz (video link - VTX)
Transmitter power (EIRP)
FCC/IC: ≤ 24 dBm
CE/SRRC/MIC: ≤ 20 dBm
Less than 20dBm for drone control
25~600 mW for Video Link
APP features
Live-View
Camera Control & Setting
Tap to Flight
Route Planning
Grid Flight Planning
Intelligent Circle
Historical Route
Auto Take-off / Return
No APP
Real-time Video Transmission
720P@30fps
800x480 (Via GL1)
5180 - 5875 MHz
FCC/IC: ≤ 24 dBm
CE/SRRC/MIC: ≤ 20 dBm
Less than 20dBm
Waterproof Camera
1 axis gimbal 4K camera (GC1-S)
2 axis gimbal low-light 1080P camera (GC2-S)
3 axis gimbal 4K camera (GC3-S)
3 axis gimbal thermal camera (GC3-T)
Fixed angle camera (FAC)
None
Payload Release Mechanism
PL1-S
TrollSafe
PL1-F (no camera)
PL2-F (with FPV camera)
TrollSafe
